Product feature
- Fully automatic type: 4-axis turret type shaft winding type, which automatically sets paper tubes, cuts sheets, and dispenses products. Fully automatic rewinding is possible, including in-line winding that winds directly from the coater and calendar, and rewinding that creates small rolls from jumbo rolls.
- Semi-automatic type: Turret type or single axis type. The operator is responsible for setting the paper tube on the take-up shaft, cutting and pasting the sheet, and removing the product.
- Check the tension with the tension controller and handle high tension and low tension.
- Optional attachment of mouth-watering paper, release paper winding device, trimming mechanism, etc. can be installed.
lineup
| 3 inch paper core model | small paper core model | |
| Fully automatic winder | PNK-024L | PNK-024S |
| Fully automatic rewinder | PNK-294 | PNK-294S |
| Semi-automatic rewinder | PNK-282 | PNK-282S |
Spec（Example）
| model | PNK-024L | PNK-024S |
| paper core inner dia. × length | 3″×1,550mm | 1″×1,400mm |
| Seat width | 1,480 mm | 1,300 mm |
| Maximum winding diameter | 230mm | 100mm |
| Maximum winding speed | 200m／分 | 150m／分 |
| Maximum line speed | 100m／分 | 55m／分 |
| Winding accuracy | +0.2m | +0.2m |
| Sheet cutting method | Saw blade or circular blade | Saw blade or circular blade |
| Tension control | Automatic tension control device | Automatic tension control device |
| tension | 1000N max. | 600N max. |
| Other | Mouth paper sticking device, release paper winding device option | Mouth paper sticking device, release paper winding device option |
- This is just an example. It may change depending on the model of the device, the size of the product to be cut, etc.
